ORIGINAL PAPER
Validation of new proprietary software (r-Algo) for predicting meat
chemical composition from ultrasound images of skeletal muscles
in live animals: Pectoralis major muscles of broiler chickens
1
University of Guelph, Ontario Veterinary College, Department of Biomedical Sciences, Guelph, Ontario, N1G 2W1, Canada
2
University of Agriculture in Kraków, Department of Animal Genetics, Breeding and Ethology; 30-059 Cracow, Poland
These authors had equal contribution to this work
Publication date: 2024-04-05
Corresponding author
P. M. Bartlewski
University of Guelph, Ontario Veterinary College, Department of Biomedical Sciences, Guelph, Ontario, N1G 2W1, Canada
University of Guelph, Ontario Veterinary College, Department of Biomedical Sciences, Guelph, Ontario, N1G 2W1, Canada
KEYWORDS
TOPICS
ABSTRACT
The objective of this study was to validate a novel computerized
method of ultrasound image analysis to determine chemical composition of
pectoralis major muscles in broiler chickens. Ultrasonograms of pectoral muscles
in the longitudinal and transverse planes were obtained from 40 birds just before
slaughter. All chemical constituents of muscle samples were determined with
the validated laboratory techniques, and the results served as a benchmark for
developing the present algorithmic estimates of chicken meat composition. An inhouse
developed algorithm (r-Algo) was used to normalize the ultrasonograms
and to identify pixel intensity ranges for which linear correlations between mean
numerical pixel values and the content of various chemical constituents were
the strongest (based on the values of correlation coefficients), using a stepwise
sequestration of ultrasound bitmaps. Percentages of chemical constituents were
the dependent (accepted) variables and the results of echotextural analyses
(luminance or pixel intensity), carried out with a commercially available image
analysis software (ImageProPlus®), were the explanatory variables. The
predictive regression equations were determined in 30 randomly selected
algorithm-training experimental units, and their accuracy was tested in a subset
of 10 birds allocated to the algorithm-validation group. Significant determination
coefficients were found for all chemical constituents studied, with the accuracy
ranging from 62.70% (linoleic acid, transverse plane, pixel range of 141–142)
to 96.65% (total hypocholesterolemic acids, longitudinal plane, pixel range of
136–150). The present validation results indicate that accurate prediction of
muscle chemical composition using echotextural image analyses is feasible
after identifying specific pixel intensity ranges.
ACKNOWLEDGEMENTS
We are indebted to Zachary Silverman
and Arvin Asgharian Rezaee (work-study
and summer students in the Department of
Biomedical Sciences, Ontario Veterinary
College) for their work on the Python version
of the r-Algo computer program and desktop
app, and Dr. David J. Hobson of the Research
Innovation Office, University of Guelph,
for his invaluable guidance with the r-Algo
patenting process. Parts of the current results
were presented, in a preliminary form, during
the Summer Career Opportunities and Research
Exploration Program Symposium (Ontario
Veterinary College, University of Guelph,
Guelph, ON, Canada; 13 August 2019), the
virtual Graduate Student Research Symposium
(Ontario Veterinary College, Universi-ty of
Guelph, Guelph, ON, Canada; 25 August 2020),
and the EAAP + WAAP + Interbull Congress in
Lyon, France (26 August- 1 September, 2023).
FUNDING
Canada Foundation for Innovation; Department
of Biomedical Sciences at the University of
Guelph, ON, Canada; University of Agriculture
in Kraków, Poland; and Ontario Pork co-funded
this study.
CONFLICT OF INTEREST
The Authors declare that there is no conflict of
interest.
REFERENCES (35)
1.
Ahmadi B., Jamieson M., Ahmadi B., Połtowicz K., Nowak J., Murawski M., Małopolska M., Schwarz T., Bartlewski P.M., 2022. Correlations between first order echotextural characteristics and chemical composition of pectoralis major muscles in broiler chickens receiving different dietary fat supplements. Ann. Anim. Sci. 22, 803–813, https://doi.org/10.2478/aoas-2....
2.
Amin V., Wilson D., Rouse G., 1997. USOFT: An ultrasound image analysis software for beef quality research. Beef Research Report. Iowa State University, Ames (IA), USA.
3.
Banzato T., Fiore E., Morgante M., Manuali E., Zotti A., 2016. Texture analysis of B-mode ultrasound images to stage hepatic lipidosis in the dairy cow: a methodological study. Res. Vet. Sci. 108, 71–75, https://doi.org/10.1016/j.rvsc....
4.
Barkved K., 2023. How To Know If Your Machine Learning Model Has Good Performance | Obviously AI Available online: https://www.obviously.ai/post/... (accessed on 6 December 2023).
5.
Berzaghi P., Dalle Zotte A., Jansson L.M., Andrighetto I., 2005.Nearinfrared reflectance spectroscopy as a method to predict chemical composition of breast meat and discriminate between different n-3 feeding sources. Poult. Sci. 84, 128–136, https://doi.org/10.1093/ps/84.....
6.
Chanamai R., McClements D.J., 1999. Ultrasonic determination of chicken composition. J. Agric. Food Chem. 47, 4686–4692, https://doi.org/10.1021/jf9813....
7.
Fabbri G., Gianesella M., Gallo L., Morgante M., Contiero B., Muraro M., Boso M., Fiore E., 2021. Application of ultrasound images texture analysis for the estimation of intramuscular fat content in the longissimus thoracis muscle of beef cattle after slaughter: a methodological study. Animals 11, 1117, https://doi.org/10.3390/ani110....
8.
Fernández-Cabanás V.M., Polvillo O., Rodríguez-Acuña R., Botella B., Horcada A., 2011. Rapid determination of the fatty acid profile in pork dry-cured sausages by NIR spectroscopy. Food Chem. 124, 373–378, https://doi.org/10.1016/j.food....
9.
Gallardo M.A., Pérez D.D., Leighton F.M., 2012. Modification of fatty acid composition in broiler chickens fed canola oil. Biol. Res. 45, 149–161, https://doi.org/10.4067/S0716-....
10.
Guilford J.P., Fruchter B., 1978. Fundamental Statistics in Psychology and Education. 6th Edition, McGraw-Hill, New York, https://scholar.google.com/sch... (accessed on 6 December 2023).
11.
Han Y.J., Hayes J.C., 1990. Soil Cover Determination Using Color Image Analysis. Transactions of the ASAE 33, 1402–1408, https://doi.org/10.13031/2013.....
12.
Haralick R.M., Shanmugam K., Dinstein I., 1973. Textural Features of Image Classification. IEEE Transactions on Systems, Man, & Cybernetics 3, 610–621, https://doi.org/10.1109/TSMC.1....
13.
Houghton P.L., Turlington L.M., 1992. Application of ultrasound for feeding and finishing animals: a review. J. Anim. Sci. 70, 930–941, https://doi.org/10.2527/1992.7....
14.
Izquierdo M., Amin V., Wilson D., Rouse G., 1996. Models to predict intramuscular fat percentage in live beef animals using realtime ultrasound and image parameters: report on data from 1991-1994. Iowa State University.
15.
Kim S.H., 2021. Method for estimating intramuscular fat percentage of Hanwoo (Korean traditional cattle) using convolutional neural networks in ultrasound images. IJASC 10, 105–116, https://doi.org/10.7236/IJASC.....
16.
Kleczek K., Wawro K., Wilkiewicz-Wawro E., Makowski W., Konstantynowicz D., 2009. Relationships between breast muscle thickness measured by ultrasonography and meatiness and fatness in broiler chickens. Arch. Anim. Breed. 52, 538–545, https://doi.org/10.5194/aab-52....
17.
Layer G., Zuna I., Lorenz A., Zerban H., Haberkorn U., Bannasch P., van Kaick G., Räth U., 1990. Computerized ultrasound B Scan texture analysis of experimental fatty liver disease: influence of total lipid content and fat deposit distribution. Ultrason. Imaging 12, 171–188, https://doi.org/10.1177/016173....
18.
McCauley J.D., Thane B.R., Whittaker A.D., 1994. Fat estimation in beef ultrasound images using texture and adaptive logic networks. Transactions of the ASAE (USA) 37, 997–1002 https://doi.org/10.13031/2013.....
19.
McLaren D.G., McKeith F.M., Novakofski J., 1989. Prediction of carcass characteristics at market weight from serial real-time ultrasound measures of backfat and loin eye area in the growing pig. J. Anim. Sci. 67, 1657–1667, https://doi.org/10.2527/jas198....
20.
Morales-Barrera J.E., Gonzalez-Alcorta M.J., Castillo-Dominguez R.M., Prado-Rebolledo O.F., Hernandez-Velasco X., Menconi A., Tellez G., Hargis B.M., Carrillo-Dominguez S., 2013. Fatty acid deposition on broiler meat in chickens supplemented with tuna oil. Food Nutr. Sci. 4, 16–20, https://doi.org/10.4236/fns.20....
21.
Newcom D.W., Baas T.J., Lampe J.F., 2002. Prediction of intramuscular fat percentage in live swine using real-time ultrasound. J. Anim. Sci. 80, 3046–3052, https://doi.org/10.2527/2002.8....
22.
Nkukwana T.T., Muchenje V., Masika P.J., Hoffman L.C., Dzama K., Descalzo A.M., 2014. Fatty acid composition and oxidative stability of breast meat from broiler chickens supplemented with moringa oleifera leaf meal over a period of refrigeration. Food Chem. 142, 255–261, https://doi.org/10.1016/j.food....
23.
Oviedo-Rondón E.O., Parker J., Clemente-Hernández S., 2007. Application of real-time ultrasound technology to estimate in vivo breast muscle weight of broiler chickens. Br. Poult. Sci. 48, 154–161, https://doi.org/10.1080/000716....
24.
Scanes C.G., 2007. The global importance of poultry. Poult. Sci. 86, 1057–1058, https://doi.org/10.1093/ps/86.....
25.
Schwarz T., Połtowicz K., Nowak J., Murawski M., Małopolska M.M., Andres K., Wojtysiak D., Jamieson M., Bartlewski P.M., 2019. Quantitative echotextural attributes of pectoralis major muscles in broiler chickens: physicochemical correlates and effects of dietary fat source. Animals 9, 306, https://doi.org/10.3390/ani906....
26.
Silva S.R., Guedes C.M., Mourão J.L., Pio A., Pinheiro V.M., 2009. The value of in vivo real time ultrasonography in assessing loin muscularity and carcass composition of rabbits. Meat Sci. 81, 357–363, https://doi.org/10.1016/j.meat....
27.
Shearer S.A., Holmes R.G., 1990. plant identification using color co-occurrence matrices. Transactions of the ASAE 33, 2037–2044, https://doi.org/10.13031/2013.....
28.
Ślósarz P., Gut A., Stanisz M., Ryszard S., Wójtowski J., Danków R., 2001. Assessment of fat content in the longissimus dorsi muscle in live lambs on basis of ultrasound image. Archiv fur Tierzucht 44, 344–350.
29.
Smulikowska S., Rutkowski A., 2005. Recommended Allowances and Nutritive Value of Feedstuffs - Poultry Feeding Standards (in Polish). The Kielanowski Institute of Animal Physiology and Nutrition PAS and Polish Branch of WPSA.
30.
Stanford K., Jones S.D.M., Price M.A., 1998. Methods of predicting lamb carcass composition: a review. Small Rumin. Res. 29, 241–254, https://doi.org/10.1016/S0921-....
31.
Szczypiński P.M., Strzelecki M., Materka A., Klepaczko A., 2009. MaZda - A software package for image texture analysis. Comput. Methods Programs Biomed. 94, 66–76, https://doi.org/10.1016/j.cmpb....
32.
Teixeira A., Joy M., Delfa R., 2008. In vivo estimation of goat carcass composition and body fat partition by real-time ultrasonography. J. Anim. Sci. 86, 2369–2376, https://doi.org/10.2527/jas.20....
33.
Thane B.R., 1992. Prediction of intramuscular fat in live and slaughtered beef animals through processing of ultrasonic images. Doctoral dissertation, Texas A&M University.
34.
Wu Z., Matsui O., Kitao A., Kozaka K., Koda W., Kobayashi S., Ryu Y., Minami T., Sanada J., Gabata T., 2015. Hepatitis C related chronic liver cirrhosis: feasibility of texture analysis of mr images for classification of fibrosis stage and necroinflammatory activity grade. PLOS ONE 10, e0118297, https://doi.org/10.1371/journa....
35.
Wood J.D., Richardson R.I., Nute G.R., Fisher A.V., Campo M.M., Kasapidou E., Sheard P.R., Enser M., 2004. Effects of fatty acids on meat quality: a review. Meat Sci. 66, 21–32, https://doi.org/10.1016/S0309-....
